Standard Stainless Enclosure
The AD Series of Stainless Steel Electrical Enclosures are still the most popular of all enclosures available.
The addition of mounting flanges to this standard enclosure has been a huge advantage when used in hostile environments by allowing the enclosure to be mounted without jeopardizing the IP rating.
|
Body
Material |
Stainless
Steel |
Gasket
Material |
Polyurethane
foam |
|
|
Grade |
316 |
Gasket
Type |
Pour
in place |
|
|
Body
Thickness |
1.5mm |
Gasket
Surface |
Smooth,
Ingress Resistant Skin |
|
|
Panel
Material |
Mild Steel |
Lock |
8mm
Triangle |
|
|
Panel
Thickness |
2mm |
Lock
Material |
Glass
Reinforced Nylon Tined Brass Insert |
|
|
Panel
Coating |
Zinc-Aluminium |
Loom
Bracket |
Fitted
to hinged side of door |
|
|
Hinge
|
Concealed
Pin |
Mounting
Provision |
27mm
Flanges |
|
|
Hinge
Material |
316
Stainless Steel |
Mounting
Holes |
8mm
x 15mm |
|
|
Door
opening |
120
degrees |
IP
Rating |
IP66 |
|
Part
No. |
Dimensions (mm) |
Access (mm) |
Panel (mm) |
Mounting (mm) |
No. |
Weight |
|||||||
|
Height |
Width |
Depth |
Height |
Width |
Depth |
Height |
Width |
Thickness |
Height |
Width |
|||
|
AD202015 |
200 |
200 |
155 |
160 |
160 |
136 |
150 |
150 |
3 |
230 |
120 |
1 |
3.0 |
|
AD302015 |
300 |
200 |
155 |
260 |
160 |
136 |
250 |
150 |
3 |
330 |
120 |
1 |
4.4 |
|
AD303015 |
300 |
300 |
155 |
260 |
260 |
136 |
250 |
250 |
3 |
330 |
220 |
1 |
5.4 |
|
AD403015 |
400 |
300 |
155 |
360 |
260 |
136 |
350 |
250 |
3 |
430 |
220 |
1 |
7.4 |
|
AD404020 |
400 |
400 |
205 |
360 |
360 |
186 |
350 |
350 |
3 |
430 |
320 |
1 |
10.3 |
|
AD504015 |
500 |
400 |
155 |
460 |
360 |
136 |
450 |
350 |
3 |
530 |
320 |
2 |
11.5 |
|
AD604020 |
600 |
400 |
205 |
560 |
360 |
186 |
550 |
350 |
3 |
630 |
320 |
2 |
14.4 |
|
AD606025 |
600 |
600 |
255 |
560 |
560 |
236 |
550 |
550 |
3 |
630 |
520 |
2 |
21.6 |
|
AD806025 |
800 |
600 |
255 |
760 |
560 |
236 |
750 |
550 |
3 |
830 |
520 |
2 |
27.5 |
